Steel Detailing

  • 3D modelling utilising Tekla Structures

  • Liaison with relevant project stakeholders including builder, engineer and architect

  • Raising RFIs and Proposals to resolve project issues

  • Provision of 2D drawings including assembly / fitting and marking plans

  • Generating reports tailored to suit client’s requirements (MTO, Bolt List, Strumis, Fabtrol, etc.)

  • Generating NC & DXF files for plates and shafts

  • Provision of developed drawings for rolled plates.
